What’s the question?

The question came up, “How much time do we spend processing the MARC vs trying to push it into Solr?”. Bob Haschart found that even with a pretty damn complicated processing stage, pushing the data to solr was still, at best, taking at least as long as the processing stage.

I’m interested because I’ve been struggling to write a solrmarc-like system that runs under JRuby. Architecturally, the big difference between my stuff and solrmac is that I use the StreamingUpdateSolrServer (on Erik Hatcher’s suggestion). So I thought I’d check how things break down for me.

Here are my numbers running under JRuby (using MARC4J as the marc implementation) with the Solr StreamingUpdateSolrServer. Obviously, there are a lot of differences between this and solrmarc, but I’m hoping that while it’s not comparing apples to apples, it’s at least comparing apples to some sort of processed cheese-like product.

What work is being done on what?

The data set is a file of 18,881 MARC records in marc-binary format. It’s probably not big enough to get a great idea of how things will run over the long (many millions of records) haul, but it’ll do for this rough-cut stuff.

I break my processing down into five categories:

• Read the records into marc4j objects and do nothing. This is a baseline of sorts.
• The “normal” fields are anything that you could do with SolrMarc without a custom routine; the actual processing is done in JRuby.
• Custom fields are generated with JRuby code, but these are things that in solmarc would require a custom routine.
• The big “allfields” field is text from tags 100 through 900.
• The “to_xml” routine is just calling the underlying marc4j XML output and stuffing it into a string.

The schema used is our normal UMICH schema except for High Level Browse (which appear in the our catalog as “Academic Discipline”). The code for that is written in Java, and I just call it from JRuby when I’m using it. I excluded it because it’s incredibly expensive, both at startup time (when it loads a giant database of call-number ranges and associated categories) and for processing — there’s a lot of call-number normalization, long-string comparisons, some modified binary searches, etc. etc. etc. It’s expensive. Trust me.

The Solr server itself is on a different, incredibly-beefy machine, and is emptied out before each invocation that involves actually pushing data to it (with a delete-by-query :).

How fast were things on my desktop?

• 18,881 records in marc-binary format
• Times are in seconds, run on my desktop
• Remember, you can’t compare these numbers to Bob’s because we’re doing different things to different data.

We can also break the same numbers down as:

Or like this:

Why does solr processing seem so much faster for me?

There are a lot of reasons why my submit-to-solr might seem like less of a burden. The ones I can think of off the top of my head are:

• SUSS is just faster than whatever solrmarc does.
• My processing stage is so much slower than solrmac’s (due to algorithms or jruby-vs-java, I don’t know) that the “push to solr” portion of it gets swallowed up by the slowness of the of overall code.
• The Solr server is so much faster than my desktop that my poor little desktop can’t send it data fast enough to work it.

For my setup, obviously adding a processing thread is a lot more beneficial than adding a SUSS thread. My desktop doesn’t have that many threads lying around (adding a third processing thread actually slowed things down), so I moved the code to a beefier machine to see what happened.

Trying the same thing on a beefy machine

This is the exact same code and data, but on a beefy machine (16 cores, gobs of memory).

So, on my hardware anyway, there’s a sweet spot with one suss thread and three processing threads. YMMV, of course.

What have we learned?

I’m not sure, to be honest. It’s logistically difficult for me to do the same process in solrmarc because I’d have to rebuild everything without the HLB stuff. I guess for me, what I’ve learned that if I’m going to continue working on my code, the places to focus my attention are threading (obviously) and MARC-XML generation.

A parser need only implement #each and a module-level method #decode_from_string.

Read all about it on the github page.

When I initially looked at MARC-HASH almost a year ago, I was mostly looking for something that wasn’t such a pain in the butt to work with, something that would marshall into multiple formats easily and would simply and easily round-trip.

Now, though, a lot of us are looking for a MARC format that (a) doesn’t suffer from the length limitations of binary MARC, but (b) is less painful (both in code and processing time) than MARC-XML, and it’s worth re-visiting.

For at least a few folks, un-marshaling time is a factor, since no matter what you’re doing, processing XML is slower than most other options. Much of that expense is due to functionality and data-safety features that just aren’t a big win with a brain-dead format like MARC, so it’s worth looking at alternatives.

What is MARC-HASH?

At some point, we’ll want a real spec, but right now it’s just this:

So, a short example:

How's the speed?

I think it's important to separate the format marc-hash from the eventual marshaling format -- partly because someone might actually want to use something other than JSON as a final format, but mostly because it forces implementations to separate hash-creation from json-creation and makes it easy to swap in different json libraries when a faster one comes along.

Having said that, in real life people are mostly concerned about JSON. So, let's look at JSON performance.

The MARC-Binary and MARC-XML files are normal files, as you'd expect. The JSON file is "Newline-Delimited JSON" -- a single JSON record on each line.

The benchmark code looks like this:

  # Unmarshal
  x.report("MARC Binary") do
    reader = MARC::Reader.new('test.mrc')
    reader.each do |r|
      title = r['245']['a']
    end
  end


# Marshal
  x.report("MARC Binary") do
    reader = MARC::Reader.new('test.mrc')
    writer = MARC::Writer.new('benchout.mrc')
    reader.each do |r|
      writer.write(r)
    end
    writer.close
  end

Under MRI, I used the nokogiri XML parser and the yajl JSON gem. Under JRUby, it was the jstax XML parser and the json-jruby JSON gem.

The test file is a set of 18,831 records I've been using for all my benchmarking of late. It's nothing special; just a nice size.

Marshalling Speed (read from binary marc, dump to given format)

Times are in seconds on my Macbook laptop, using ruby-marc.

Unmarshalling speed (from pre-created file)

Again, times are in seconds

And so...

I'm not sure what else to say. The format is totally brain-dead. It round-trips. It's fast enough. It has no length limitations. We define it to have to be UTF-8. The NDJ format is easy to understand and allows streaming of large document collections.

If folks are interested in implementing this across other libraries, that'd be great. Any thoughts?

**NOTE** It strikes me that I haven’t seen a case where bad data results from sending a valid LCCN. The only verified problem is one of false negatives. Send a valid lccn, you’ll get back either good data or nothing (and the “nothing” might be in error). So, still a big problem, but not as THESKYISFALLING as I imply below.

A long time ago, Jonathan Rochkind noted that the OCLC doesn’t correctly normalize their LCCNs.

Well, it’s not fixed.

I could really, really use the xlccn service right about now — a great web service they provide that, much like xisbn and xissn and the other xXXXX (heh!) services, purports to allow you to put in an lccn and get data back on the item you’re interested in.

Except they “normalize” their LCCNs in a way that is not only incorrect, but causes namespace collisions. As near as I can tell, they throw out any leading non-digits and only keep up to the next non-digit.

The xLCCN service will silently provide no data or incorrect data for many LCCN requests!

An example:

• (F) Full LCCN is “sn 83011407″
• (D) First set of digits is “83011407″. This is what I think the OCLC is indexing.
• (N) Correct normalization is “sn83011407″

The problem, of course, is that (D) “83011407″ is itself a valid LCCN.

• (F) is associated with OCLC# 47212967
• (D) is associated with OCLC# 12505148. That’s not the same record.

So, how do the OCLC services respond?

• (F) Worldcat search finds correct (probably just doing a string match); xid finds nothing
• (D) Worldcat finds both correct and incorrect records. The xLCCN service finds only the incorrect record, OCLC# 12505148.
• (N) Neither worldcat nor xid finds anything for the correctly normalized version.

So, what am I supposed to do? Only use the service on LCCNs where the original and normalized versions are the same and include only digits? Frustrating.

Working with Solr

I love me the Solr. I love everything about it except that the best way to interact with it is via Java. I don’t so much love me the java.

So…taking Erik Hatcher’s lead and advice, as I will do whenever he offers either, I wrote some code to work within JRuby to deal with Solr.

Getting the code

I’ve added the gems to gemcutter, if you want to play along at home:

• jruby_producer_consumer (github, rdoc.info) Ruby syntax for threaded operations under jruby
• jruby_streaming_update_solr_server (github, rdoc.info) Ruby syntax on top of the Java class of the same name
• marc4j4r (github, rdoc.info) Ruby syntax on top of the marc4j java library.

WARNING: None of these gems have a 1.0 version tag on them, and that means that the API may change a titch in the future. Also, the fact that they’re released as gems means that it’s easy to release gems, not that I’m not an idiot.

The basics: Using SolrInputDocument and StreamingUpdateSolrServer

OK, with the disclaimer out of the way, let’s look at some code.

Nothing really fancy in there — just a few things worth noting:

• An suss object will take a hash (again, anything that responds to #each_pair) or a SolrInputDoc
• You can use either strings or symbols to represent Solr field names
• Values can be either a single value, or an array of multiple values

And there are three ways to get data into a doc:

• Via << [field, value(s)] (additive)
• Via doc.merge! hash (additive)
• Via doc[field] = value (replaces)

Adding Threads

I also went down the garden path of threading things. There are an awful lot of operations that are not threadsafe (e.g., reading a line from a file) but once you’ve got a bunch of records to worth with, turning them into Solr documents is usually thread-safe.

My model is that there’s a producer (usually the method #each) from an underlying data object. A thread takes whatever that method yields and sticks the values into a java BlockingQueue awaiting consumption. You then use ProdcuerConsumer#threaded_each (or ProducerConsumer#threaded_each_with_index) to pull items out of the queue and do something useful with them.

I extracted stuff into a library (jruby_producer_consumer) for your viewing pleasure.

CONFUSION ALERT: It’s perhaps unfortunate that the object you send to ProducerConsumer.new(obj) must implement #each and that the ProducerConsumer method #threaded_each calls that underlying #each…well there’s a lot of #each’s floating around. Keep them straight.

So…let’s look at some code to work with consumer threads.

Again, not a lot happening here.

• The “producer” is always one thread, because so little is thread-safe at the ‘each’ level. In this case, there’s a single thread pulling data out of the file and turning it into MARC records, which are added to the internal BlockingQueue. I buffer 5 of these at a pop (the default) so the consumer threads don’t starve. I presume that producing items is cheaper than consuming them, or else this library won’t help you much.
• ProducerConsumer#threaded_each calls the #each method of the underlying object. You can substitute anything that yields, though, as in this example where I call #each_line instead of the default #each

• Keep track of your threads. In this last example, there is one thread getting MARC records and putting them into the PC buffer (no way to change that), three threads consuming those records and sticking them into the suss object, and another two pulling stuff out of the suss object and sending things to Sorl. And, of course, there’s other stuff running on the computer, too. Experiment and figure out what works best for your hardware.
• See the docs for how to mess with what goes into a ProducerConsumer object. It’s entirely possible to use, say, #each_slice. There’s also a convenience method #threaded_each_with_index, but it does not call the underlying #each_with_index, it produces its own index as things are read.

Feedback not only welcome but necessary!

I’ve done a lot of messing around with Ruby in the last 10 days or so, but I’m still basically converting from Perl in my head. Any comments, bugs reports, or whatnot are definitely welcome!

[YUCK! It was a disaster in a few ways! Don't look at this! It's hideous! There's a new jruby_producer_consumer gem on gemcutter that is slightly different from this in that it works. Ignore the stuff below.]

[In working on a threaded JRuby-based MARC-to-Solr project, I realized that my threading stuff was...ugly. And I didn't really understand it. So I dug in today and wrote this.]

I’ve just pushed to Gemcutter my first gem — a JRuby-only producer/consumer class that works with anything that provides #each called jruby_producer_consumer.

It’s JRuby-only because it uses (a) A blocking queue implemenation that’s native Java, and (b) threading, which isn’t a huge win under regular Ruby.

There’s no testing there because I’m not sure how to test threaded stuff

It is, I hope, easy to use:

On our ridiculously-awesome hardware, right now we’re doing about 300 records/second for short files and 250 records/second for a full (6.5 million record) index, giving us a 7-8 hour reindex.

I’ll just post the results without a lot of commentary. I warmed stuff up in all cases, and ran on my desktop (so I could compare to MRI ruby, which isn’t installed on the server) and on the server where we usually run these things.

• The machines are my desktop OSX machine and the beefy linux server where we usually do this stuff
• The platforms are jruby 1.4 –server and MRI ruby 1.87
• The libraries are marc4j and ruby-marc 0.3.3
• The parsers are
  • The standard binary parsers all around
  • A home-grown AlephSequential format reader for the ’seq’ type. AlephSequential is a MARC representation that uses one line for each field. We use it because it doesn’t have length limitations and, not surprisingly, Aleph can spit it out pretty quickly compared to MARC-XML.
  • Whatever marc4j uses internally for MARC-XML
  • ruby-marc’s ‘jstax’ xml parser under jruby (which I wrote and apparently needs some love, see below)
  • ruby-marc’s ‘libxml’ xml parser under MRI ruby
• Seconds is the average of two rounds, with measurements taken after a warmup run in each case.

The test files were 18,881 records in marc-xml, marc-binary, and AlephSequential formats.

MACHINE  PLATFORM LIBRARY     PARSER    SECONDS    REC/SECOND

desktop  jruby    marc4j      binary      4.06       4650
desktop  jruby    marc4j      xml         5.55       3401
desktop  jruby    ruby-marc   binary     17.35       1088
desktop  jruby    ruby-marc   jstax      80.11        236

desktop  ruby     ruby-marc   binary     33.54        562
desktop  ruby     ruby-marc   libxml     46.87        402

server   jruby    marc4j      binary      2.29       8245
server   jruby    marc4j      xml         3.36       5619
server   jruby    marc4j      AlephSeq    3.68       5130
server   jruby    ruby-marc   binary      9.93       1901
server   jruby    ruby-marc   jstax      44.56        424

The quick takeaways, with all the obvious caveats:

• jruby with ruby-marc is twice as fast at binary and twice as slow at xml compared with MRI
• marc4j is four times as fast for binary and about an order of magnitutde faster for xml compared with ruby-marc.
• The server is fast.

We know from previous experience that libxml is the fastest of the current MRI-based marc-xml readers and that jstax is the best of the current jruby-based marc-xml readers. And, finally, we know that many of us can’t use marc-binary format because our records are too big.

If I’m gonna use jruby (which I think I am due to wanting to use the StreamingUpdateSolrServer) I’m gonna need to use marc4j and just wrap it up in some nicer syntax.

So, initially, this post listed that the way to separate multiple simultaneous requests was with a nice, URL-like slash (/) character.

Then, I remembered that LCCNs can have embedded slashes, e.g., 65063380//r85.

So, we’re back to using pipe (|) characters to separate multiple calls — the examples below have been updated to reflect this.

Introduction

I’ve put up a beta version of the HathiTrust Volumes API previously discussed on this blog and via email.

Currently, I’ve only got json output, although there is space in there for other output formats as necessary.

What exactly is this?

Given: an identifier or set of identifiers, this API will Return: a set of matched records and a sorted list of the items available in the HathiTrust.

Useful, for example, if you want to display HathiTrust holdings alongside your own in your OPAC.

Simple, single-value call

Given the URL:

http://catalog.hathitrust.org/api/volumes/oclc/15420548.json

You’ll get the following back:

Note that the ‘records’ are keyed on the local umid, also available in the ‘fromRecord’ field of each item.

The generic short form is:

http://catalog.hathitrust.org/api/volumes/(idtype)/id.(outputtype)

Right now the valid idtypes are:

• issn (will be normalized to just digits, no leading zeros)
• isbn (will be normalized to an ISBN-13)
• oclc (will be normalized to all digits, no leading zeros)
• lccn (will be normalized as recommended)
• htid (HathiTrust item id, seen above as “mdp.39015058510069″)
• umid (the University of Michigan record ID, seen above in the “fromRecord” field of an item)

Currently the only valid outputtype is ‘json’.

More complex, multi-valued call

The full API URL looks like this:

http://catalog.hathitrust.org/api/volumes/json/id:1;oclc:45678;lccn:70628581|id:2;isbn:1591581613

This is a request for data on two separate items, identified on the calling end as simply ‘1′ and ‘2′ (id:1 and id:2). The first item is searched for using both an oclc number and an lccn; the second supplies only an isbn.

Note that

• The output format (json) has moved to appear right after the ‘/volumes/’
• There’s an arbitrary ‘id’ field. This will be used to index the return values, so use something meaningful on your end.
• keys and values are separated by colons. Key-Value pairs are separated by semi-colons.
• Separate requests are separated by ‘/’ in the URL, allowing you to request data for an arbitrary number of items with a single call.
• Return values are
• Matches follow the “#3″ option on the old post, the “Must match if present” option — basically, if you supply an identifier and a record has one of those identifiers, they must match.

So, in the example, the first request has both an oclc number and an lccn. Matches are as follows:

• If a record has an oclc number but no lccn, its oclc number must match the passed oclc number.
• If a record has an lccn but no oclc number, its lccn must match the passed lccn value.
• If a record has both an lccn and an oclc number, both its identifiers must match the passed values.

The returned structure is keyed on the arbitrary id passed in the search string (if not present, the whole search string will be used instead):

Enumeration / Chronology

An effort is made to return items in “enumcron order” — hopefully, with earlier volumes showing up before later volumes. The full enumcron is listed in the items if you need to try something different.

JSONP Support

JSONP output is supported — just throw a ‘&callback=blahblahblah’ on the end of the URL you call and you’ll get a function definition back.

Some examples:

http://catalog.hathitrust.org/api/volumes/oclc/15420548.json&callback=myfunc

http://catalog.hathitrust.org/api/volumes/json/id:1;oclc:45678;lccn:70628581/id:2;isbn:1591581613&callback=myfunc

There was much pain. Much, much pain. Exacerbated by my almost complete lack of knowledge about what I was doing.

This is the procedure I eventually arrived at — if there are places where I made trouble for myself, please let me know!

[And does anyone know how to get jruby's nokogiri to link to a different libxml and stop with the crappy libxml2-version error message every time I run it under OSX???]

Download jruby

Go to jruby.org and download a binary distribution. Extract the tar.gz (or zip or whatever)

I’ll put mine in ~/jruby. Or, at least that’s what I’ll tell you.

tar xzf jruby-1.4.tar.gz

To avoid confusion, let’s make jrake an alias for rake and add the jruby bin directory to the path

cd ~/jruby/bin
ln -s rake jrake
export PATH=`pwd`:$PATH

Download Blacklight

git clone git://github.com/projectblacklight/blacklight.git

Again, well say that I put this in ~/blacklight/

Muck with Blacklight dependencies

Edit the file init.rb to comment out references to libxml and ruby-xslt, as well as nokogiri. My understanding is that the first two are used, at this point, only for the EAD stuff. Both rely on libxml2 which is a C-extension and hence unavailable to JRuby.

Nokogiri gets pulled in during other installs and for some reason jrake will complain later on that it’s got a wrong version or something. So, we’ll just work without that particular net for now.

#### File ~/blacklight/init.rb
# config.gem 'libxml-ruby', :lib=>'libxml', :version=>'1.1.3'
# config.gem 'ruby-xslt', :lib=>'xml/xslt', :version=>'0.9.6'
# config.gem 'nokogiri', :version=>'1.3.3'

Do some initial installs

jgem install -v=2.3.4 rails
jgem install activerecord-jdbc-adapter jdbc-sqlite3
             activerecord-jdbcsqlite3-adapter ActiveRecord-JDBC
jgem install rcov -s http://gemcutter.org --no-rdoc --no-ri
jrake
jrake gems:install

Edit the config/database.yml file

…to change the adapter to jdbcsqlite3 for development and testing.

Edit the databases.rake file

This one was harder to track down. The default rake task has hard-coded database names in the .rake file — jdbcsqlite3 isn’t included. I keep seeing things saying, “Oh, yeah, that’s been fixed…” but, well, it wasn’t for me. I had to do it by hand.

edit ~/jruby/lib/ruby/gems/1.8/gems/rails-2.3.4/lib/tasks/databases.rake

You need to find everywhere there’s a

when "sqlite", "sqlite3" # or when /^sqlite/ in one case

…and change it to

when "sqlite", "sqlite3", "jdbcsqlite3"

Repeat for other databases you want to use (e.g., mysql). For the moment, since I’m only worried about running jrake spec, that’s all I’m gonna do.

Try again

jrake
  Missing these required gems:
   mislav-hanna  = 0.1.11

OK. Not sure why that didn’t come in before. Go head and add it.

jgem install  mislav-hanna

Migrate the databases

jrake

The databases should migrate, and then it’ll poop out because Solr didn’t start.

Fire up solr

Since we’re running jruby, accessing the shell doesn’t work. You’ll have to fire up your test solr instance by hand.

cd ~/blacklight/jetty
java -Djetty.port=8888 -jar start.jar 2>log.jetty

Try it again!

cd ~/blacklight
jrake spec

   ................................................................
   ................................................................
   ....F............................................................
   1)
   'ApplicationHelper Export EndNote should render the correct
   EndNote text file' FAILED
   expected: "%0 Format\n%E Greer, Lowell. \n%E Lubin, Steven. \n%E Chase, Stephanie, \n%E Brahms, Johannes, \n%E Beethoven, Ludwig van, \n%E Krufft, Nikolaus von, \n%T Music for horn \n%I Harmonia Mundi USA, \n%C [United States] : \n%D p2001. \n",
  got: "%0 Format\n%C [United States] : \n%D p2001. \n%E Greer, Lowell. \n%E Lubin, Steven. \n%E Chase, Stephanie, \n%E Brahms, Johannes, \n%E Beethoven, Ludwig van, \n%E Krufft, Nikolaus von, \n%I Harmonia Mundi USA, \n%T Music for horn \n" (using ##)
./spec/helpers/application_helper_spec.rb:128:

Finished in 15.519 seconds
193 examples, 1 failure

I can live with that for the moment. Anyone know why that spec fails?

Great! How about the features?

jrake features
  (much output)

  59 scenarios (59 passed)
  434 steps (434 passed)
  0m51.186s

And so…

…it appears that, at least on the surface, jruby is a viable platform for Blacklight so long as I don’t actually need any of the libxml stuff. In the next couple days I’ll try and actually get it all up and running and see if I can break it.

Let’s get them to play nice with each other!

How’s it all work?

1. Zotero looks for a well-constructed <link> tag in the head of the page
2. It checks the document on the other side of that link to see what formats are offered, and picks one to use. No, you can’t decide which one it uses. It picks.
3. Zotero then looks for IDs in the body of the page
4. If both are found and everything seems kosher, Zotero will offer the option to import some or all of the records.

What you’ll need

1. An OPAC whose output you can futz with
2. Access to an individual record’s ID in that output
3. A URL based on the ID that gives an RIS representation of the records
4. A screwdriver. Made with decent — but not too expensive — vodka and fresh orange juice.

Yes. I’m cheating.

I have all those things already. Hence, this is easy for me. If you had to, say, write some sort of weird redirection script because IDs are not first-class citizens in your OPAC’s URL scheme, or write an RIS export tool by hand, well, this will take you a bit longer.

The process

1. Build an upAPI target script

You need a script that’ll do three things:

1. With no arguments, return a list of available formats in general
2. With one argument, id=<ID>, return a list of formats available for that item. This will likely be exactly the same as #1.
3. With two arguments, id=<ID> & format=<FORMAT>, return the record identified by <ID> in format <FORMAT>

Mine looks like this:

You can see that a <format> is a just a name, a mime-type, and an optional reference to documentation on the type.

I take advantage of my existing RIS export process in the redirect, at the bottom. I also built in the possibility that other types of numbers could come in — I’m hard-coding ‘bibnum’ for the moment, but could allow, say, “oclc” or “isbn” or whatnot, too.

2. Tell your OPAC where the script lives

You’ll need a line in the <head> section of all your pages that might have an ID on them:

<link rel="unapi-server" type="application/xml" title="unAPI" href="/unapi">

Everything should be left alone except for the actual href.

3. Add your IDs to the HTML

In the HTML of your page, you can add one or more tags of the form:

<abbr class="unapi-id" title="urn:bibnum:000000002"></abbr>

(where the title of the <abbr> conforms to what you’re expecting in your script).

You can put stuff inside the <abbr> but you need not. On a single-record page, you should have (I would think) only one of these things. On a search results page, you may decide to not have any, or you may decide to have one for each search result.

4. Final step

Drink your screwdriver.

Where can I see it?

Well…here’s the thing.

You can take a look at my test instance, http://dueberb.vufind.lib.umich.edu/ and play there. You can not see it in production, because there’s a little problem.

Our old OPAC — now dubbed mirlyn-classic — had a custom translator written for it. And it worked fine, and that was great.

But now we’ve got this new software running at mirlyn.lib.umich.edu, and Zotero keeps on using the old translator no matter what you do. The only way to override it is to actually fire up sqlite3 and remove the conflicting entry from the zotero translators table. And then never update that table again.

I’ve asked around about getting it fixed (changing the target URL for the old translator to point at mirlyn-classic) but it’s Friday, and no one is around. Hopefully soon.
